Performer RPM Ford Small Block 302 Intake Manifold, Chrome Plasma Finish

Details

Edelbrock Part # 7121-CP Performer RPM 302 intake manifold is designed for street 289-302 c.i.d. Ford V8's. This dual-plane high rise manifold has excellent high rpm power while retaining throttle response. No provisions for exhaust heated choke. Edelbrock carbs will work with Ford automatic overdrive trans (AOD) when used with Lokar bracket SRK-4000, for more info call (865) 966-2269 or go to www.lokar.com.

PRODUCT SPECS

More Information
Part Type	Engine Intake Manifold
Manufacturer	Edelbrock
Application	Application Specific
UPC	085347898374
Series	Performer RPM
Material	Aluminum
Finish	Chrome Plasma
Gasket Or Seal Included	No
Vehicle Model	Ford
Availability Note	Available to Order
Warranty	12 Months
RPM Range	1500-6500 RPM
Emissions Code
Application Summary	Ford:Small-Block Windsor:260 (4.3L)/289 (4.7L)/302 (5.0L)
Hazardous Materials Warning	WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
Installation Notes	Will not fit 255 c.i.d. V8. Recommended intake gasket: Edelbrock # 7220. Manifold Height: A-4.30", B-5.50" Carb pad height: 4.90" Carb recommendations: Edelbrock AVS2 or Performer Series 600-750 cfm. Port exit dimensions: 1.05" x 1.86" Use RTV sealant to properly seal end seals, such as Edelbrock High Temp Silicone sealant #1076, DO NOT USE END SEALS GASKETS. Hardened washers Must be used with intake bolts to ensure proper torque and prevent galling of the aluminum.
Color	Chrome
Rear Maximum Height	5.500 in
Single Or Dual Plane Type	Dual
