Manifold & Install Kit, SB Ford RPM Air-Gap 7521 w/ Gaskets, Bolts, Studs, RTV

$531.95

Upgrade your existing Small-Block Ford intake manifold to the powerful RPM Air Gap. This kit # 7521-KIT contains commonly needed installation items all in one box, including the manifold, gaskets, intake bolts, and carb studs.

In stock

SKU

7521-KIT

Details

Easily upgrade your existing Small-Block Ford to the powerful Edelbrock RPM Air-Gap intake manifold with this all-in-one box solution, eliminating the guesswork from the installation while saving you time and money. This kit includes an RPM Air-Gap intake manifold (#7521) for a Small-Block Ford, along with all the commonly needed installation items such as the gaskets, intake bolts, and carburetor studs.

PRODUCT SPECS

More Information
Part Type	Engine Intake Manifold / Carburetor Kit
Manufacturer	Edelbrock
Application	Application Specific
UPC	085347899517
Series	RPM Air-Gap
Material	Aluminum
Finish	Satin
Vehicle Model	Ford
Availability Note	Available to Order
Warranty	12 Months
RPM Range	1500-6500 RPM
Emissions Code
Features and Benefits	Includes manifold, gaskets, intake bolts and carb studs. No guess work. All items in one box.
Application Summary	Ford:Small-Block:289 (4.7L)-302 (5.0L)
Hazardous Materials Warning	WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
Installation Notes	Will not fit 255 c.i.d. V8; Not recommended for 289; Recommended intake gasket: Edelbrock #7220; Manifold Height: A-4.30", B-5.50"; Carb pad height: 4.90"; Carb recommendations: Edelbrock AVS2 or Performer Series 600-800 cfm. For automatic transmissions use #1483 and #1490 or #1844.; Port exit dimensions: 1.04" x 1.85"; Use RTV sealant to properly seal end seals, such as Edelbrock High Temp Silicone sealant #1076, DO NOT USE END SEALS GASKETS.; Hardened washers Must be used with intake bolts to ensure proper torque and prevent galling of the aluminum.
Rear Maximum Height	5.500 in
Single Or Dual Plane Type	Dual
